Power Supplies


CPS1

5 VDC Battery Pack for CPS Laser Diodes

LDS9

9 VDC Regulated Power Supply

EC5PS

OEM-Style Power Supply

DS5

5 VDC, 2 A Power Supply with USB 2.0 Type-A Port

  • Output Voltages Ranging from 5 VDC to 24 VDC
  • Location-Specific Power Cord or Adapter Included

KCH601

USB Controller Hub and Power Supply for Six K-Cubes™ or T-Cubes™

Related Items


Please Wait

Thorlabs offers a variety of power supplies with output voltages ranging from 5 VDC to 24 VDC. Our OEM-style power modules are available in 15 W and 100 W units with three voltage outputs: +5 VDC, ±12 VDC, and ±15 VDC.

Power Supplies
Item # Output Voltage Output Current Connector Type Compatible Products
LDS5
LDS5-EC
5 VDC 330 mA 2.5 mm Phono Plug CPS Laser Modules
CPS1 5 VDC 2 A 2.5 mm Phono Plug & USB
DS5 5 VDC 2 A USB Type-A Female DXM20AF,
LCC2415-VIS(/M),
Any Product Requiring 5 V Power via USB
LDS9
LDS9-EC
9 VDC 220 mA 2.5 mm Phono Plug OEM Laser Diode Drivers
DS12 12 VDC 4 A M8 Connector PTC1
(PTC1/M)
LDS12B  ±12 VDC 250 mA LUMBERG RSMV3 Male Connector (3 Pins) PDA and PDB Amplified Photodetectors, PDA Series Silicon PhotomultipliersDET Biased Detectors, PMM Photomultiplier Modules, APD Avalanche Photodetectors, and FSAC
DS15 15 VDC 1.3 A Mini-XLR Nanosecond Pulsed Laser Systems
KPS201 15 VDC 2.66 A Female DC, 3.5 mm OD KBD101, KDC101, KIM101, KLS635, KLS1550, KSC101, KST201, LEDD1B, and TIA60
TPS002 ±15 VDC / 5 VDC 2.5 A @ 5 VDC
0.5 A @ +15 VDC
0.3 A @ -15 VDC
8-Pin Mini Din Plug (2 Places) KPZ101, KNA-VIS, KNA-IR,
KPA101, and KSG101
KCH301 15 VDC 10 A 26 Way 1.27 Pitch, ERNI Connector (6 Places) All K-Cubes™ and T-Cubes™
KCH601
EC2PSa ±12 VDC / 5 VDC 2 A @ 5 VDC
0.2 A @ ±12 VDC
 5 Available Output Connector Pins (Please Refer to the Manufacturing Spec Sheet for Pinout Table) For use in Custom Electronic Assemblies
EC3PSa ±15 VDC / 5 VDC 2 A @ 5 VDC
0.15 A @ ±15 VDC
EC4PSa ±12 VDC / 5 VDC 10 A @ 5 VDC
3 A @ +12 VDC
0.8 A @ -12 VDC
 12 Available Output Connector Pins (Please Refer to the Manufacturing Spec Sheet for Pinout Table)
EC5PSa ±15 VDC / 5 VDC 10 A @ 5 VDC
3 A @ +15 VDC
0.8 A @ -15 VDC
DS24 24 VDC 6.67 A KPPX-3P, 3-Pin Male MCM301 3-Axis Stepper Motor Controller for Microscopy
  • This power supply is designed to operate in a grounded enclosure which is protected against electrical and fire hazards. It is not intended for stand-alone or hands-on use under any circumstance.

Posted Comments:
Ilmars Celmins  (posted 2022-11-14 14:10:38.737)
I purchased the CPS1 battery pack and two PL202 laser modules, planning to plug both lasers into the battery pack. However, this doesn't work because the laser USB connectors are too wide to fit side by side (or the battery pack ports are too close together, depending on how you look at it). Not happy. I guess I'll need to buy some kind of USB extension cable or adapter, which will take months and hundreds of dollars due to government purchasing efficiency. Any other suggestions?
Back to Top

5 VDC Regulated Power Supply

  • Compatible with CPS Laser Modules
  • 5 VDC Power Output
  • 6 ft (183 cm) Cable with 2.5 mm Phono Plug

The LDS5 is a 5 VDC power supply that is ideal for use with our CPS laser diode modules. A 6 ft (183 cm) cable with a 2.5 mm phono plug extends from the body of the power supply for connection to a CPS module.

The power supply has a selectable line voltage of 115 or 230 VAC, which is controlled by a switch near the power switch. A 120 VAC power cable is included with the LDS5, while the LDS5-EC comes with a 230 VAC power cable. To order this item with a different power cable, please contact Tech Support.

Based on your currency / country selection, your order will ship from Newton, New Jersey
+1 Qty Docs Part Number - Imperial Price Available
LDS5 Support Documentation
LDS55 VDC Regulated Power Supply, 2.5 mm Phono Plug, 120 VAC
$101.29
Today
+1 Qty Docs Part Number - Metric Price Available
LDS5-EC Support Documentation
LDS5-EC5 VDC Regulated Power Supply, 2.5 mm Phono Plug, 230 VAC
$101.29
Today
Back to Top

5 VDC External Battery Pack

  • Portable USB Battery Pack with 5 VDC and up to 2 A Output
  • Compatible with CPS Laser Modules and USB-Powered Devices
  • 10 000 mAh Capacity

Thorlabs offers the CPS1 Battery Pack for powering our CPS laser modules and other USB-powered devices. The CPS1 battery pack outputs 5 VDC at up to 2 A, and offers 10 000 mAh capacity. A fully charged CPS1 battery pack can power any CPS laser module for at least 36 hours of continuous operation. The pack includes a USB-to-Micro-USB cable for charging and a custom USB-to-Phono cable for powering the CPS laser module. To activate the battery, simply push the power button once. The pack may be charged using standard 5 V USB chargers for portable devices or using a computer USB port. While the battery pack is charging, it can still supply power to an attached laser module.

The CPS1 Battery Pack also includes an LED flashlight adjacent to the micro-USB port. The flashlight is activated and deactivated by holding the power for two seconds.

When connecting the CPS Diode Module, the module and adapter should be connected first. Then the adapter cable should be plugged into the isolated power supply to avoid a short circuit in the phono jack. Please note that the USB adapter included with this battery pack is not intended to be used with power supplies that are not current-limited or isolated from ground, such as some computers or laptops.

Please note: Due to shipping restrictions for lithium ion cells, the CPS1 battery pack is not available for purchase in certain countries. In countries where it is available, the battery pack must be shipped separately using specifically regulated shipping methods and may require special shipping and handling charges. Our sales team is available to answer additional questions concerning the shipment of this battery pack.
