Socket Head Cap Screws, Stainless Steel


  • 2-56, 4-40, M3 x 0.5, 8-32, M4 x 0.7, 1/4"-20, and M6 x 1.0
    Socket Head Cap Screws
  • Vented, Vacuum-Compatible Cap Screws
  • #8 (M4) to 1/4" (M6) Counterbore Adapters
  • 1/4" and #8 Washers

SH25S075

1/4"-20 Cap Screw,
3/4" Long

SH6MS16V

Vented, Vacuum-Compatible
M6 Cap Screw, 16 mm Long

SH3M8

M3 x 0.5 Cap Screw,
8 mm Long

W8S038

#8 Washer

SH8S038

8-32 Cap Screw
3/8" Long

Related Items


Please Wait

Features

  • 2-56, 4-40, M3 x 0.5, 8-32, M4 x 0.7, 1/4"-20, and M6 x 1.0 Socket Head Cap Screws
  • Stainless or Alloy Steel Construction
  • Vented, Vacuum-Compatible 1/4"-20 and M6 x 1.0 Cap Screws Available
  • #8 (M4) to 1/4" (M6) Counterbore Adapters Also Available
  • Ideal for Replenishing our Hardware Kits
