10 mm (0.39") Travel or Less Motorized Actuators


  • High-Resolution Piezo Inertia, Stepper, and DC Servo Actuators
  • Compatible with a Wide Range of Stages
  • Velocities up to 5 mm/s

PIAK10VF

10 mm Travel
Piezo Inertia Actuator,
Vacuum Compatible

Z906

6 mm Travel, DC Actuator

DRV208

8 mm Travel,
Stepper Motor Actuator

ZFS06

6 mm Travel, Compact
Stepper Motor Actuator

Related Items


Please Wait
Back to Top

6 mm Travel Compact Stepper Motor Actuator

Required Controller:
KST201

  • 49,152 Microsteps per Revolution
  • 15 V Output at 12 W
  • Trapezoidal and
    'S-Curve' Velocity Profiles

Features

  • Compact Package: 86.5 mm (3.40") Long, Fully Retracted
  • Manual Adjustment via Rear-Located Thumbscrew
  • Non-Rotating Drive Tip
  • Compatible with Mirror Mounts and Translation Stages with 1/4"-80 Threads
  • Also Available in 13 mm and 25 mm Travel Versions

Our ZFS06 Motorized Actuator provides smooth, precise linear motion control in a sleek, compact package measuring just 86.5 mm (3.40") in length when fully retracted. This compact profile reduces the distance between the end of the actuator and optomechanical components, keeping the center of mass closer to the contact point than the ZST206 actuator featured above. This actuator has a 1/4"-80 threaded barrel that can be mounted to any manual mirror mount or positioning stage equipped with 1/4"-80 threads.

Powered by a small-diameter, two-phase, bi-polar stepper motor, this actuator operates at speeds of up to 2.0 mm/s. The non-rotating drive tip reduces wear and friction and improves smoothness of motion by removing rotational contact at the tip. If power is not supplied to the actuator, manual adjustment is achievable using the rear-located thumbscrew. The actuator motor can be damaged if this thumbscrew is rotated while power is being supplied to the motor.

Our ZFS06 actuator incorporates a stepper motor that provides sufficient torque for loads up to 40 N (8.99 lbs). The actuator allows for very small step sizes over the entire travel range, delivering greater flexibility with low (<15 µm) backlash and fine resolution. The design incorporates a 400:9 gear reduction head which, when combined with the 49,152 microsteps per revolution offered by the KST201 stepper motor driver, gives a theoretical travel per microstep of 0.46 nm (see the Calculations tab for details).

Item # ZFS06
Travel 6 mm (0.24")
Backlasha <15 µm
Bidirectional Repeatability <5.0 µm
Home Location Accuracy <5.0 µm
Maximum Load Capacity 40 N (8.99 lbs)
Velocity 2.0 mm/s (Max)
Acceleration 10 mm/s2 (Max)
Gearbox Ratio 400:9
(Approx. 44:1)
Limit Switches Hall Effect
Lead Screw Pitch 1.0 mm
Motor Type 2-Phase Stepper
Microsteps per Revolution of the Motorb 24 Full Steps, 2048 µsteps per Full Step
49,152 µsteps per Revolution
Calculated Minimum Incremental Motionc 0.46 nm
Operating Temperature 5 to 40 °C (41 to 104 °F)
Dimensions (L x W x H) 86.5 mm x 35.0 mm x 19.0 mm
(3.40" x 1.38" x 0.75")
Cable Length 0.6 m (2 ft)
Connector HDDB15
Required Controller KST201
  • The user can correct for backlash errors by adjusting software settings.
  • Measured using Thorlabs' previous generation TST101 T-Cube™ Stepper Motor Controller.
  • See the Calculations tab for more information.

Hall effect limit switches prevent the unit from being overdriven and provide homing capability with an accuracy of <5.0 μm. The ZFS series actuators come with 0.6 m (2 ft) of cable terminated in a 15-pin D-Type connector (see the Pin Diagrams tab) that is compatible with our KST201 stepper motor controller. A 1 m (3.3 ft) extension cable (PAA614) is available separately.

The ZFS06 has been designed specifically to replace the manual adjusters in stages and mirror mounts that have 1/4"-80 threaded fittings, particularly in applications where space is tight. Simply remove the existing manual adjuster from the mount and screw in the ZFS06 actuator. Two ZFS06 motorized actuators replace the thumbscrews of the KM100 in the image below.


Click to Enlarge

A KM100 mirror mount with the screw adjusters replaced by two ZFS06 actuators.

How to calculate the linear displacement per microstep

The ZFS series of motors has 24 full steps per revolution, and when driven by the KST201 drivers, there are 2048 microsteps per full step, giving 49,152 microsteps per revolution of the motor. The output shaft of the motor goes into a 400:9 gear head. This requires the motor to rotate 44.445 times to rotate the 1.0 mm pitch lead screw one revolution. The end result is the lead screw advances by 1.0 mm.


Linear displacement of the lead screw per microstep:

Number of Microsteps x Gearbox Ratio = 49,152 x 44.445 = 2184560.64

The linear displacement of the lead screw per microstep is

1.0 mm / 2184560.64 = 0.46 x 10-6 mm = 0.46 nm

Pin Diagram

Schematic
High-Density D-Type Male 15 Pin Connector

Connector Pin Out

Pin Description Pin Description
1 Limit Ground 8 Reserved for Future Use
2 CCW Limit Switch 9 Reserved for Future Use
3 CW Limit Switch 10 Vcc (+5 VDC)
4 Motor Phase B - 11 Reserved for Future Use
5 Motor Phase B + 12 Reserved for Future Use
6 Motor Phase A - 13 Reserved for Future Use
7 Motor Phase A + 14 Reserved for Future Use
 - 15 Ground
Connectors Terminating the Converter Cable
Click to Enlarge

High-Density D-Type Male 15 Pin Connector

Posted Comments:
Franklin Wei  (posted 2022-12-05 00:17:39.137)
Is there an equivalent of ZFS06 which can be fitted to an SCP05 X-Y 0.5" translation mount? Our application requires a very compact actuator with 1mm of travel in X and Y for automatic confocal pinhole alignment.
DJayasuriya  (posted 2022-12-05 10:59:25.0)
Thank you for your inquiry. Unfortuantely we dont have cage mounts that would work with actuators yet. We have got in touch with you directly to discuss your application.
Based on your currency / country selection, your order will ship from Newton, New Jersey
+1 Qty Docs Part Number - Universal Price Available
ZFS06 Support Documentation
ZFS06Customer Inspired! 6 mm Travel, Compact Stepper Motorized Actuator, 1/4"-80 Threaded
$1,312.65
Today
Back to Top

6 mm Travel Stepper Motor Actuator

Required Controller:
KST201

  • 49,152 Microsteps per Revolution
  • 15 V Output at 12 W
  • Trapezoidal and
    'S-Curve' Velocity Profiles

Features

  • Non-Rotating Drive Tip
  • Bi-Polar Stepper Motor Actuator: 111.0 mm (4.37") Long
  • 1/4"-80 Threaded Barrel Mounting
  • Compatible with Mirror Mounts and Translation Stages with 1/4"-80 Threads
  • Also Available in 13 mm and 25 mm Travel Versions

Our ZST series actuators provide smooth, precise linear motion control in a package measuring 111.0 mm (4.37") in length. Powered by a small-diameter, two-phase, bi-polar stepper motor, this actuator operates at speeds of up to 2.0 mm/s. The non-rotating drive tip reduces wear and friction and improves smoothness of motion by removing rotational contact at the tip. This actuator has a 1/4"-80 threaded barrel that can be mounted to any manual mirror mount or positioning stage equipped with 1/4"-80 threads.

Our ZST200 line of actuators all incorporate a stepper motor that provides sufficient torque for loads up to 40 N (8.99 lbs). The actuator allows for very small step sizes over the entire travel range, delivering greater flexibility with low (<15 µm) backlash and fine resolution. The design incorporates a 41:1 gear reduction head which, when combined with the 49,152 microsteps per revolution offered by the KST201 stepper motor driver, gives a theoretical travel per microstep of 0.5 nm (see the Calculations tab for details).

Item # ZST206
Travel 6 mm (0.24")
Backlasha <15 µm
Bidirectional Repeatability <5.0 µm
Home Location Accuracy <5.0 µm
Maximum Load Capacity 40 N (8.99 lbs)
Velocity 2.0 mm/s (Max)
Acceleration 10 mm/s2 (Max)
Gearbox Ratio 29791:729 (Approx. 41:1)
Limit Switches Hall Effect
Lead Screw Pitch 1.0 mm
Motor Type 2-Phase Stepper
Microsteps per Revolution of the Motorb 24 Full Steps, 2048 µsteps per Full Step
49,152 µsteps per Revolution
Calculated Minimum Incremental Motion 0.5 nm
Operating Temperature 5 to 40 °C (41 to 104 °F)
Dimensions (L x W) 111.0 mm x 19.0 mm
(4.37" x 0.75")
Cable Length 0.6 m (2 ft)
Connector HDDB15
Required Controller KST201
  • The user can correct for backlash errors by adjusting software settings
  • Measured using Thorlabs' previous generation TST101 T-Cube™ Stepper Motor Controller.

Hall effect limit switches prevent the unit from being overdriven and provide homing capability with an accuracy of <5.0 μm. This actuator comes with 0.6 m (2 ft) of cable terminated in a 15-pin D-Type connector that is compatible with our KST201 stepper motor controller. A 1 m (3.3 ft) extension cable (PAA614) is available separately.

The ZST206 has been designed specifically to replace the manual adjusters in stages and mirror mounts that have 1/4"-80 threaded fittings. Simply remove the existing manual adjuster from the mount and screw in the ZST206 actuator.


Click to Enlarge

A KM100 mirror mount with the screw adjusters replaced by two ZST206 actuators.

How to calculate the linear displacement per microstep

Each member of the ZST200 series of motors has 24 full steps per revolution, and when driven by the KST201 drivers, there are 2048 microsteps per full step. Hence, there are 49,152 microsteps per revolution of the motor. The output shaft of the motor goes into a 40.866:1 gear head. This requires the motor to rotate 40.866 times to rotate the 1.0 mm pitch lead screw one revolution. The end result is the lead screw advances by 1.0 mm. To calculate the linear displacement of the actuator per microstep, use the following:


Linear displacement of the lead screw per microstep:

Number of Microsteps x Gearbox Ratio = 49,152 x 40.866 = 2,008,645.63

The linear displacement of the lead screw per microstep is

1.0 mm / 2,008,645.63 = 0.49 x 10-6 mm = 0.5 nm

Pin Diagram

Schematic
High-Density D-Type Male 15 Pin Connector

Connector Pin Out

Pin Description Pin Description
1 Limit Ground 8 Reserved for Future Use
2 CCW Limit Switch 9 Reserved for Future Use
3 CW Limit Switch 10 Vcc (+5 VDC)
4 Motor Phase B - 11 Reserved for Future Use
5 Motor Phase B + 12 Reserved for Future Use
6 Motor Phase A - 13 Reserved for Future Use
7 Motor Phase A + 14 Reserved for Future Use
 - 15 Ground
Connectors Terminating the Converter Cable
Click to Enlarge

High-Density D-Type Male 15 Pin Connector

Posted Comments:
No Comments Posted
Based on your currency / country selection, your order will ship from Newton, New Jersey
+1 Qty Docs Part Number - Universal Price Available
ZST206 Support Documentation
ZST2066 mm Travel, Stepper Motorized Actuator, 1/4"-80 Thread
$1,105.96
Today
Back to Top

6 mm Travel DC Servo Motor Actuator

Required Controller:
KDC101

  • 34,555 Microsteps per Revolution
  • 15 V Output at 2.5 W
  • Trapezoidal Velocity Profile
Item # Z906
Travel Range 6 mm (0.24")
Encoder Resolutiona 34,555 counts/mm
(Linear Displacement)
Maximum Pushing Force 45 N
Homing Repeatability ±5 µm
Uncompensated Backlash 6 µm
Uncompensated Bidirectional Repeatability ±3 µm
Residual Backlash After Compensationb 0.1 µm
Compensated Bidirectional Repeatability ±0.3 µm
Travel Accuracyc 6 µm
Minimum Repeatable Incremental Movement 0.2 µm
Maximum Speedd 2.6 mm/s
Maximum Acceleration 4 mm/s2
Maximum Phase to Phase Resistance 33.0 Ω
Maximum Phase to Phase Inductance 0.6 mH
Tested Lifetimee >100,000 Cycles
Operating Temperature Range 41° to 104° F (5° to 40° C)
Weight 0.13 kg
Motor Typef DC Servo
Cable Length 485.0 mm (19.09")
Required Controller KDC101
  • See Calculations tab for details.
  • For an inward move, the system moves 300 µm beyond the target location to compensate for known backlash.
  • Default backlash compensation is present against a constant force.
  • At 2.6 mm/s, velocity ripple and distortion of the acceleration/deceleration profile may occur. For improved control, the maximum speed should be limited to 2.3 mm/s.
  • Tested with a load of 9 N on the lead screw.
  • Variable voltage under pulse width modulation (PWM) from a 15 V supply.

Features

  • DC Servo Actuator
  • Sub-Micron Resolution
  • Maximum Operating Speed: 2.6 mm/s
  • Drop-In Replacement for Most 6 mm Manual Actuators
  • Compatible with 1/4"-80 Thread-Fitting Stages and Mounts
  • Limit Switches for Zero Datum and Actuator Protection
  • Also Available in 12 mm and 25 mm Travel Versions

Thorlabs' Z906 motorized actuators are engineered for use with optical positioning devices such as mirror mounts and stages. They offer high resolution in a lightweight package, which makes these actuators ideally suited for demanding optical laboratory automation applications.

Electromechanical limit switches provide overdrive protection and accurate home positioning. The incorporated motor is capable of speeds up to 2.6 mm/s, but a maximum operating speed of 2.3 mm/s is recommended to maintain the specified control. The precision of the encoder (512 counts per motor revolution) results in a minimum resolution of about 29 nm. See Calculations tab for details.

The Z906 has been designed specifically to replace the manual adjusters in stages and mirror mounts that have 1/4"-80 threaded fittings. Simply remove the existing manual adjuster from the mount, and screw in the actuator. The image below shows a KM100 mirror mount with one of the screw adjusters replaced by a Z906 actuator. The units are shipped with one 485 mm (1.6') cable. A 2.5 m (8 ft) extension cable (Item # PAA632) is available separately.

The KDC101 DC Servo Controller is the required driver for the Z9 series actuators. The latest version of the Kinesis software can be downloaded here. Firmware version 2.2.8 or higher, included in the Kinesis software version 1.14.40 or higher download, is required for using the KDC101 with the Z9 actuators. Prior versions of firmware will operate the Z9 actuators but will call the actuators Z8.

For applications with longer travel requirements, see our 12 mm travel Z912 and 25 mm travel Z925 actuators. We also offer the Z906V vacuum-compatible version, which is rated for use down to 10-6 torr and is shipped with a 1.6' flat ribbon cable, IDC connector, and converter cable for use with the KDC101 controller. See below for more details.

Z906 in Km100
Click to Enlarge

View Imperial Product List
Item #QtyDescription
Z90616 mm Motorized DC Actuator, 1/4"-80 Thread Fitting, 485 mm Cable
KM1001Kinematic Mirror Mount for Ø1" Optics
ME1-P011Ø1" Protected Silver Mirror, 3.2 mm Thick
PH21Ø1/2" Post Holder, Spring-Loaded Hex-Locking Thumbscrew, L = 2"
TR21Ø1/2" Optical Post, SS, 8-32 Setscrew, 1/4"-20 Tap, L = 2"
SH8S05018-32 Stainless Steel Cap Screw, 1/2" Long, 50 Pack
CF1251Clamping Fork, 1.24" Counterbored Slot, Universal
SH25S06311/4"-20 Stainless Steel Cap Screw, 5/8" Long, 25 Pack
View Metric Product List
Item #QtyDescription
Z90616 mm Motorized DC Actuator, 1/4"-80 Thread Fitting, 485 mm Cable
KM1001Kinematic Mirror Mount for Ø1" Optics
ME1-P011Ø1" Protected Silver Mirror, 3.2 mm Thick
PH50/M1Ø12.7 mm Post Holder, Spring-Loaded Hex-Locking Thumbscrew, L=50 mm
TR50/M1Ø12.7 mm Optical Post, SS, M4 Setscrew, M6 Tap, L = 50 mm
SH4MS121M4 x 0.7 Stainless Steel Cap Screw, 12 mm Long, 50 Pack
CF1251Clamping Fork, 1.24" Counterbored Slot, Universal
SH6MS121M6 x 1.0 Stainless Steel Cap Screw, 12 mm Long, 25 Pack
A KM100 mirror mount with one screw adjuster replaced with Z906 actuator.

Pin Diagram

Schematic
High-Density D-Type Male 15 Pin Connector

Connector Pin Out

Pin Description Pin Description
1 Ground (Limit and Vcc) 9 Resistive Identification
2 Forward Limit 10 +5 VDC
3 Reverse Limit 11 Encoder Channel A
4 Reserved for Future Use 12 Reserved for Future Use
5 Motor (-) 13 Encoder Channel B
6 Reserved for Future Use 14 Pin 2 Ident EEPROM
7 Motor (+) 15 Pin 1 Ident EEPROM
8 Reserved for Future Use
Connectors Terminating the Converter Cable
Click to Enlarge

High-Density D-Type Male 15 Pin Connector

How to Calculate the Linear Displacement per Encoder Count

For the Z906, there are 512 encoder counts per revolution of the motor. The output shaft of the motor goes into a 67.49:1 planetary gear head. This requires the motor to rotate 67.49 times to rotate the 1.0 mm pitch lead screw one revolution. The end result is the lead screw advances by 1.0 mm.

The linear displacement of the actuator per encoder count is given by

512 x 67.49 = 34,555 encoder counts per revolution of the lead screw,

whereas the linear displacement of the lead screw per encoder count is given by

1.0 mm / 34,555 counts = 2.9 x 10-5 mm (29 nm).


Posted Comments:
No Comments Posted
Based on your currency / country selection, your order will ship from Newton, New Jersey
+1 Qty Docs Part Number - Universal Price Available
Z906 Support Documentation
Z9066 mm Motorized DC Actuator, 1/4"-80 Thread Fitting, 485 mm Cable
$856.80
Today
Back to Top

6 mm Travel Vacuum-Compatible DC Servo Motor Actuator

Item # Z906V
Travel Range 6 mm (0.24")
Encoder Resolutiona 34,555 counts/mm
(Linear Displacement)
Maximum Pushing Force 45 N
Homing Repeatability ±5 µm
Uncompensated Backlash 6 µm
Uncompensated Bidirectional Repeatability ±3 µm
Residual Backlash After Compensationb 0.1 µm
Compensated Bidirectional Repeatability ±0.3 µm
Travel Accuracyc 6 µm
Minimum Repeatable Incremental Movement 0.2 µm
Maximum Speedd 2.6 mm/s
Maximum Acceleration 4 mm/s2
Maximum Phase to Phase Resistance 33.0 Ω
Maximum Phase to Phase Inductance 0.6 mH
Tested Lifetimee >100,000 Cycles
Operating Temperature Range 41° to 104° F (5° to 40° C)
Vacuum Rating 10-6 Torr
Weight 80 g
Motor Typef DC Servo
Cable Length 485.0 mm (19.09")
Required Controller KDC101
  • See Calculations tab for details.
  • For an inward move, the system moves 300 µm beyond the target location to compensate for known backlash.
  • Default backlash compensation is present against a constant force.
  • At 2.6 mm/s, velocity ripple and distortion of the acceleration/deceleration profile may occur. For improved control, the maximum speed should be limited to 2.3 mm/s.
  • Tested with a load of 9 N on the lead screw.
  • Variable voltage under pulse width modulation (PWM) from a 15 V supply.

Features

  • 6 VDC Servo Actuator
  • Sub-Micron Resolution
  • Maximum Operating Speed: 2.6 mm/s
  • Drop In Replacement for Most 6 mm Manual Actuators
  • Compatible with 1/4"-80 Thread-Fitting Stages and Mounts
  • Limit Switches for Zero Datum and Actuator Protection
  • Vacuum-Rated to 10-6 Torr
  • Also Available in 12 mm and 25 mm Travel Versions

The Z906V actuator offers features and specifications similar to the Z906 actuator described above with the added benefit of being vacuum compatible down to 10-6 Torr. It incorporates vacuum-rated servo motors, a phosphorus bronze internal coupling mechanism and mounting bush, and high-vacuum grease.

The Z906V actuator is shipped with a 485 mm (1.6') vacuum-compatible flat ribbon cable with an IDC connector. This cable has 1.27 mm (0.05") pitch, 28 AWG stranded conductors and fluorinated ethylene propylene (FEP) insulation. A converter cable for use with the KDC101 controller is also supplied, but it is not vacuum compatible and should only be used outside the chamber.

The KDC101 DC Servo Controller is the required driver for the Z9 series actuators. The latest version of the Kinesis software can be downloaded here. Firmware version 2.2.8 or higher and Kinesis software version 1.14.44 or higher are required for using the KDC101 with the Z9 vacuum-compatible actuators.

For applications with longer travel requirements, see our 12 mm travel Z912V and 25 mm travel Z925BV actuators. For vacuum compatible versions of our stages and mirror mounts, please contact Tech Support.

Required Controller:
KDC101

  • 34,555 Microsteps per Revolution
  • 15 V Output at 2.5 W
  • Trapezoidal Velocity Profile

How to Calculate the Linear Displacement per Encoder Count

For the Z906V, there are 512 encoder counts per revolution of the motor. The output shaft of the motor goes into a 67.49:1 planetary gear head. This requires the motor to rotate 67.49 times to rotate the 1.0 mm pitch lead screw one revolution. The end result is the lead screw advances by 1.0 mm.

The linear displacement of the actuator per encoder count is given by

512 x 67.49 = 34,555 encoder counts per revolution of the lead screw,

whereas the linear displacement of the lead screw per encoder count is given by

1.0 mm / 34,555 counts = 2.9 x 10-5 mm (29 nm).

The vacuum-compatible cable integrated with the Z906V actuator is terminated in a female IDC 10-Pin socket connector. A short converter cable, which adapts this female IDC socket connector to a D-type male HD15 pin connector, is included with the Z906V actuator to facilitate connecting it to the recommended KDC101 controller. This converter cable, whose terminating connectors are shown below, is not vacuum compatible.  Information describing the pin assignments for both the female IDC socket and male D-type HD connector (when it is connected to the female IDC socket connector) follows.

Pin Diagram

IDC Socket Pin Diagram
10 Pin Female IDC Socket Connector
(Amphenol T812 Series, 2.54 mm Pitch)
Connectors Terminating the Converter Cable
Click to Enlarge

10 Pin Female IDC Socket Connector
(Amphenol T812 Series, 2.54 mm Pitch)

Female IDC 10-Pin Connector Pin Out

Pin Description Pin Description
1 Motor (+) 6 Motor (-)
2 Vcc 7 Limit Ground
3 Channel A 8 Reverse Limit
4 Channel B 9 Forward Limit
5 Ground 10 Not Connected

Pin Diagram

Schematic
High-Density D-Type Male 15 Pin Connector

Male HDDB15 Connector Pin Out

Pin Description Pin Description
1 Ground (Limit and Vcc) 8 Reserved For Future Use
2 Forward Limit 9 Ident Resistor
3 Reverse Limit 10 Vcc (+5 VDC)
4 Reserved For Future Use 11 Encoder Channel A
5 Motor (-) 12 Reserved for Future Use
6 Reserved for Future Use 13 Encoder Channel B
7 Motor (+) 14, 15 Reserved For Future Use
Connectors Terminating the Converter Cable
Click to Enlarge

Connectors terminating the converter cable. The image on the left shows the high-density D-type male 15-pin connector, and the image on the right shows the 10-pin male IDC socket connector.

Posted Comments:
No Comments Posted
Based on your currency / country selection, your order will ship from Newton, New Jersey
+1 Qty Docs Part Number - Universal Price Available
Z906V Support Documentation
Z906VVacuum-Compatible 6 mm Motorized DC Actuator, 1/4"-80 Thread Fitting
$1,122.00
Today
Back to Top

8 mm Travel Stepper Motor Actuator

Compatible Controller:
BSC201

  • 409,600 Microsteps per Revolution
  • 48 V Output at 25 W
  • Trapezoidal and
    'S-Curve' Velocity Profile
Item # DRV208
Travel 8 mm (0.3")
Unidirectional Repeatability 3.6 µm
Bidirectional Repeatability 5.0 µm
Absolute Accuracy 17.1 µm
Maximum Force 180 N
Maximum Velocity 5 mm/s
Maximum Acceleration 5 mm/s2
Full Step Angle 1.8°
Feedback None
Limit Switches Hall Effect
Lead Screw Pitch 0.5 mm
Homing Repeatability 13.5 µm
Motor Type 2-Phase Stepper
Microsteps per Revolution of Leadscrew 409,600
Compatible Controllers BSC201
MST602

Features

  • 8 mm Total Travel
  • High Maximum Force of 180 N
  • Non-Rotating Drive Tip
  • 500 mm (19.7") D-Type Connection Cable Attached
  • 3 m Extension Cable Included
  • MCA1 and MCA2 Adapters Convert to Ø3/8" or Ø10 mm Mounting Barrel

The DRV208 Modular Stepper Motor Actuator is designed to be used with our 3-axis and 6-axis NanoMax™ flexure stages. The M22 x 0.75 threaded flange interfaces directly with the NanoMax stage, making it easy to select an actuator for each axis based on the user's requirements. Using the MCA1 or MCA2 quick-connect adapters, this actuator can also be fitted to a stage with standard Ø3/8" or Ø10 mm mounting clamps, respectively. Additionally, the DRV208 drive is compatible with the DRV120 piezo drive, which adds 20 µm of electronically controlled piezo-actuated travel.

This actuator features an 8 mm travel range and is capable of speeds up to 5 mm/s. The powerful stepper motor driver has a maximum force of 180 N.

The knurled knob on the rear shaft of the motor can function as a manual adjuster when the actuator is powered down. Note that in an open-loop system, manually adjusting the actuator position will desynchronize the actuator from the position display in the control software. This can be corrected by homing the actuator back to its original zero position, which should be done immediately upon powering up the actuator. The knob also serves as an inertial damper which absorbs vibrations from the stepper motor.

A 500 mm (19.7") cable with a 15-pin D-type connector is attached to the unit to connect the stepper motor to a controller. The unit also comes with a 3 m (9.8 ft) extension cable (item # PAA613). If a shorter cable is needed, the 1 m (3.3 ft) PAA612 cable is available separately.

NanoMax Modular Actuators
Click to Enlarge

The DRV208 can be installed on a 3-axis NanoMax stage.

How to Calculate the Linear Displacement per Microstep

The stepper motor used in the DRV208 actuator has 200 full steps per revolution of the motor. Each full step is broken down into 2048 microsteps. There are 409,600 microsteps per revolution of the motor when using the BSC201 controller. The end result is the leadscrew advancing by 0.5 mm. To calculate the linear displacement of the actuator microstep, use the following:

409,600 microsteps per revolution of the lead screw

The linear displacement of the lead screw per microstep is:

0.5 mm / 409,600 = 1.2 x 10-6 mm

To calculate the linear displacment for a full step, substitute 409,600 with 200.

Pin Diagram

Schematic
High-Density D-Type Male 15 Pin Connector

Connector Pin Out

Pin Description Pin Description
1 Limit Switch 0 V 9 For Future Use
2 Limit Switch 0 V 10 +5 V
3 CW Limit Switch 11 -
4 Motor Phase B -ve 12 -
5 Motor Phase B +ve 13 +5 V
6 Motor Phase A -ve 14 -
7 Motor Phase A +ve 15 Ground
8 - - -
Connectors Terminating the Converter Cable
Click to Enlarge

High-Density D-Type Male 15 Pin Connector

Posted Comments:
guanghai zhang  (posted 2020-05-03 09:19:19.12)
Hellow, can this modtor be controler by BCS101, the last generation controlor? Best, Weili
DJayasuriya  (posted 2020-05-05 04:39:03.0)
Thank you for your inquiry. Unfortunately these new motor types are not implemented in our legacy firmware used with BCS101. Sorry
alfred  (posted 2016-09-10 13:00:27.96)
Dear Sir: I come from Chroma ATE Inc. I have some question for this apt™ Stepper Motor Controllers Type:BSC203 with Motor Type :DRV001(see on the motor's connecter) 1.I'd like to know device unit about the motor: (nm/Pulse?) According to ThorLab official specification value: a.Minimum Incremental Movement:60nm/pulse.Does device unit? b.Lead Screw Pitch:0.5mm.Does express motor rotation one circle forward 0.5mm? c.Microsteps per Revolution of Leadscrew:Does express motor rotation one circle need 409600pulse? So (Lead Screw Pitch/Microsteps per Revolution of Leadscrew)=Minimum Incremental Movement,but 1.2nm is not equal 60nm ,why? 2.Kinesis software(Actuator set APT600L X Axis) a.Step Size=0.5mm: motor rotation one circle forward 0.5mm? but autaul half circle I see. b.Travel:8mm ,but I could move 12 mm (show on the current device postion). Does I configuration error? Thank you.
bwood  (posted 2016-09-12 11:09:51.0)
Response from Ben at Thorlabs: Thank you for your feedback. I believe this relates to the conversion between microsteps to real world units. For the DRV001 connected to the BSC203, 1mm equates to 819200µs. I will be in direct contact with you so I can gather more details on your system, and troubleshoot you Kinesis issue in more detail.
alfred  (posted 2016-09-09 13:13:17.31)
Dear Sir: I come from Chroma ATE Inc. I have some question for this apt™ Stepper Motor Controllers Type:BSC203 with Motor Type :8 mm Travel Stepper Motor Actuator As I use Win32 development(refernece ThorLab exmaple code),set velocity=3838090,position=1715200,Acceleration=2253,Motor vibration occurs,(unit:device unit) but use Kinesis's APP(Version:1.7.0.0),set velocity=2.5,position=10,Acceleration=2,Motor move smooth,(unit:mm) 1.I'd say that this is not the exact setting we wanted on Win32 code. 2.What number is the Minimum Incremental Movement? Thank you.
bwood  (posted 2016-09-12 08:36:18.0)
Response from Ben at Thorlabs: Thank you for your feedback. The answers to these questions will depend on the specific method you are using to control your BSC203, and the system you are trying to build. We will be in direct contact to get further details on your setup and to discuss how to control the BSC203.
jjurado  (posted 2011-03-22 09:46:00.0)
Response from Javier at Thorlabs to benju: Thank you for contacting us with your request. The DRV001 actuators are not compatible with the T-Cube controllers, as they require a higher current input in order to be operated. I will contact you directly for further support.
benju  (posted 2011-03-22 01:53:48.0)
can this be operated with a t-cube stepper controller as well?
klee  (posted 2009-09-24 10:02:13.0)
A response from Ken at Thorlabs to jean-thomas.landry: No, the drawing is not showing it at maximum extension. The minimum length is 134mm and the maximum length is 142mm.
jean-thomas.landry  (posted 2009-09-23 11:18:40.0)
good morning, Is the pdf drawing of drv001 showing it at maximum extension? regards,
Based on your currency / country selection, your order will ship from Newton, New Jersey
+1 Qty Docs Part Number - Universal Price Available
DRV208 Support Documentation
DRV2088 mm Travel, Modular NanoMax Stepper Motor Actuator
$613.38
Today
MCA1 Support Documentation
MCA1Modular Quick-Connect Adapter, Ø9.525 mm (Ø3/8") Mounting
$22.37
Today
MCA2 Support Documentation
MCA2Modular Quick-Connect Adapter, Ø10 mm Mounting
$22.37
Today
Back to Top

10 mm Travel Piezo Inertia Actuator

Required Controller:
KIM001 or KIM101

  • KIM001: Single-Channel Output
  • KIM101: Four Output Channels, Capable of Multi-Channel Operation
  • Standalone Control via Top Panel or PC Control via USB
  • Voltage Output from 85 V to 125 V
Inertia Motor
Click for Details

The control cable can be adjusted up to 110° for space-constrained applications.

Features

  • Compact Design: 31.5 mm x 17.0 mm (W x H)
  • 20 nm Typical Step Size
  • Manual Adjustment via Knob on Adjuster Screw
  • 125 V Maximum Operating Voltage
  • 1/4"-80 Mounting Thread for Compatibility with Mirror Mounts
  • Also Available in 13 mm, 25 mm, and 50 mm Travel Versions for Translation Stages
  • Ideal for Set-and-Hold Applications that Require High-Resolution Relative Positioning

Thorlabs' PIAK10 Piezoelectric Inertia Actuator provides high-resolution linear motion control with a long piezo translation range in a compact package. It can support loads up to 2.5 kg (5.51 lbs) and preloads up to 30 N with typical movements of 20 nm and no backlash. The step size can be adjusted up to 30% to a maximum of approximately 30 nm using the KIM101 Controller and Kinesis® software. However, due to the open-loop design, piezo hysteresis, and application conditions such as the direction of travel, the achieved step size of the system can vary by up to 20% and is not normally repeatable. An external feedback system will need to be used to overcome this variance.

This actuator has a 1/4"-80 threaded barrel that can be mounted to manual mirror mount or positioning stages equipped with 1/4"-80 threads. The actuator is self-locking when at rest and when there is no power supplied to the piezo, making the actuator ideal for set-and-hold applications that require nanometer resolution and long-term alignment stability. Manual adjustments can be made using the knob on the adjuster screw, as long as the piezo is not actively translating the screw; the knob is also compatible with 5/64" (2.0 mm) hex keys.

Powered by a 10 mm long discrete piezo stack, the actuator can operate at speeds of up to 3.5 mm/minute. The design of the piezo motor will rotate the tip of the lead screw during translation. For information on the design of our piezo inertia "slip-stick" motor actuators, please see the complete presentation here.

Item # PIAK10
Travel 10 mm (0.39")
Typical Step Sizea 20 nm
Maximum Step Sizeb <30 nm
Step Size Adjustabilityc ≤30%
Maximum Step Frequencyd 2000 Hz
Backlash None
Maximum Active Preloade 30 N
Typical Angular Resolutionf Ø1" Mirror Mounts: 0.5 μrad
Ø2" Mirror Mounts: 0.3 μrad
Recommended Maximum
Axial Load Capacityg
2.5 kg (5.51 lbs)
Speed (Continuous Stepping)
2 mm/minute (Typical)
<3.5 mm/minute (Maximum)
Drive Screw 1/4"-80 Thread, Hard PVD Coated
Motor Type Piezoelectric Inertia
Mounting Feature
(Auxiliary)
1/4"-80 Thread with Lock Nut
(Ø3/8" [Ø9.525 mm] Barrel)
Operating Temperature 10 to 40 °C (50 to 104 °F)
Dimensions 72.9 mm x 31.5 mm x 17.0 mm
(2.87" x 1.24" x 0.67”)
Cable Length 1.0 m (3.28 ft)
Connector SMC, Female
Required Controllerh KIM001 or KIM101
  • This value can vary by up to 20% and is not normally repeatable due to component variance, change of direction, and application conditions.
  • This can be adjusted up to 30% in both directions using the controller and Kinesis Software.
  • This can be Adjusted using the controller and Kinesis Software.
  • Using the KIM101 Inertia Piezo Controller
  • The axial force applied to the drive tip to achieve the specified step size. A minimum of 5 N is recommended to enhance stepping behavior.
  • The typical angular resolution when a PIAK10 Actuator is fitted to a Ø1" or Ø2" mirror mount with a maximum active preload of 30 N.
  • A higher maximum load is possible but it may decrease the typical step size.
  • Controllers are sold separately. These actuators can also be controlled using the legacy TIM101 T-Cube™ controller.

Required Controller
A KIM001 or KIM101 Controller is required to operate our PIAK10 Piezo Inertia Actuator; the actuator cannot be operated using a standard piezo controller. These drivers have internal sawtooth voltage signal generators capable of sending sub-millisecond pulses (steps) with controllable amplitudes from 85 V to 125 V.

For more information, please see the full web presentation.

Inertia Motor
Click to Enlarge

Two PIAK10 Inertia Actuators Being Used in Place of the
1/4"-80 Adjustment Screws in our KM100 Mirror Mount
(Mount Sold Separately)

Posted Comments:
Filip Munz  (posted 2019-08-20 00:43:57.353)
Is this Piezo Inertia Actuator (PIAK10) suitable for high vacuum (cca 0.5 mtorr)? Or can we use rather integrated optic mount like KC1-P? The purpose is a sample adjustment in the chamber. Can you provide also a suitable feedthrough (ideally with KF40 dimensions)?
rmiron  (posted 2019-08-20 05:31:14.0)
Response from Radu at Thorlabs: Hello Filip. Unfortunately, PIAK10 is completely unsuitable for vacuum applications. However, we are very seriously looking into expanding our range of vacuum-compatible products. I will relay your feedback internally in the hope that it will accelerate the process. In the meantime, you could use POLARIS-K1S2P or POLARIS-K1S3P which are piezo-driven, vacuum compatible, 1" mounts. The Polaris line also contains vacuum-compatible posts. If longer travel ranges are required, you could use our Z812V or Z812BV vacuum-compatible actuators. With regards to feedthroughs, we only offer KF16 & KF25 ones on our website (https://www.thorlabs.com/newgrouppage9.cfm?objectgroup_id=12861). However, we could offer KF40 ones as a custom item. If you would like to order such custom feedthroughs, please contact your local technical support team.
Jin Ic Kim  (posted 2019-03-28 23:06:49.767)
When I use two PIAK10 in KM100 mirror mount, contact point of one out of two hole is not surface, so there is damage occurs at the tip of actuator as the tip rotates. The other comment is that the actuator seems not return its position when I start at 0 to 20000, then send signal to return 0, sometimes big deviation I have. I'm doing wrong?
user  (posted 2019-04-03 07:31:30.0)
Response from Arunthathi at Thorlabs: Thanks for your query. I have contacted you directly requesting for further information to troubleshoot the issue
Based on your currency / country selection, your order will ship from Newton, New Jersey
+1 Qty Docs Part Number - Universal Price Available
PIAK10 Support Documentation
PIAK10Piezo Inertia Actuator, 10 mm Travel, 1/4"-80 Mounting Thread
$604.66
Today
Back to Top

10 mm Travel Vacuum-Compatible Piezo Inertia Actuator

Required Controller:
KIM001 or KIM101

  • KIM001: Single-Channel Output
  • KIM101: Four Output Channels, Capable of Multi-Channel Operation
  • Standalone Control via Top Panel or PC Control via USB
  • Voltage Output from 85 V to 125 V
Inertia Motor
Click for Details

The flying lead can be adjusted up to 110° for space-constrained applications.

Features

  • Compact Design: 31.5 mm x 17.0 mm (W x H)
  • 20 nm Typical Step Size
  • Manual Adjustment via Knob on Adjuster Screw
  • Rated Down to 10-6 Torr
  • 125 V Maximum Operating Voltage
  • 1/4"-100 Mounting Thread for Compatibility with KS1TV Ø1" Mirror Mount
  • Ideal for Set-and-Hold Applications that Require High-Resolution Relative Positioning
  • Vacuum-Compatible PIA13VF Actuator for Translation Stages Also Available

Thorlabs' PIAK10VF Vacuum-Compatible Piezoelectric Inertia Actuator is rated down to 10-6 Torr operation and provides high-resolution linear motion control with a long piezo translation range in a compact, vacuum-compatible package. It can support loads up to 2.5 kg (5.51 lbs) and preloads up to 30 N with typical movements of 20 nm and no backlash. The step size can be adjusted up to 30% to a maximum of approximately 30 nm using a compatible controller and the Kinesis® software. However, due to the open-loop design, piezo hysteresis, and application conditions such as the direction of travel, the achieved step size of the system can vary by up to 20% and is not normally repeatable. An external feedback system will need to be used to overcome this variance.

The actuator is self-locking when at rest and when there is no power supplied to the piezo, making the actuator ideal for set-and-hold applications that require nanometer resolution and long-term alignment stability. Manual adjustments can be made using the knob on the adjuster screw, as long as the piezo is not actively translating the screw; the knob is also compatible with 5/64" (2.0 mm) hex keys.

This actuator has a 1/4"-100 threaded barrel that can be mounted to the KS1TV mirror mount or other mounts with non-matched 1/4"-100 actuators. Note that the PIAK10VF actuator is not compatible with Polaris® mounts that use 1/4"-100 adjusters. These mounts require a specific actuator ball size and tip design to ensure that the ball contact is centered on the sapphire end stone and that there is proper screw clearance during full translation. In the case of the PIAK10VF actuator, the side of the screw, rather than the ball tip, will contact the sapphire end stone and, as a result, the actuator should not be used with Polaris mounts.

Each actuator has an integrated 0.75 m flying lead, plus 1.0 m of cored cable for wiring outside the vacuum chamber. The flying leads and cored cable lengths can be cut down as needed, but the total length (inside and outside) should not exceed 2.0 m. As shown in the image above, the flying lead for each actuator can be rotated up to 110° for space-constrained applications.

Powered by a 10 mm long discrete piezo stack, the actuator can operate at speeds of up to 3.5 mm/minute. The design of the piezo motor will rotate the tip of the lead screw during translation. For information on the design of our piezo inertia "slip-stick" motor actuators, please see the complete presentation here.

Item #a PIAK10VF
Travel 10 mm (0.39")
Typical Step Sizeb,c 20 nm
Maximum Step Size 30 nm
Step Size Adjustabilityc ≤30%
Maximum Step Frequency 2000 Hz
Backlash None
Maximum Active Preloadd 30 N
Typical Angular Resolution KS1TV Ø1" Mirror Mount: 0.5 μrad
Recommended Maximum
Axial Load Capacitye
2.5 kg (5.51 lbs)
Speed (Continuous Stepping)
2 mm/minute (Typical)
<3.5 mm/minute (Maximum)
Drive Screw 1/4"-80 Thread, Hard PVD Coated
Motor Type Piezoelectric Inertia
Mounting Feature
(Auxiliary)
1/4"-100 Thread with Lock Nutf
(Ø3/8" [Ø9.525 mm] Barrel)
Operating Temperature 5 to 130 °C (41 to 266 °F)
Dimensions 77.7 mm x 31.5 mm x 17.0 mm
(3.06" x 1.24" x 0.67")
Cable Length 0.75 m (2.48 ft) Flying Lead for Vacuum,
1.0 m (3.3 ft) of Cored Cable for Wiring Outside Chamber
Connector SMC, Female
Vacuum Rating 10-6 Torr
Required Controllerg KIM001 or KIM101
  • Specifications are measured using the KIM101 Piezo Inertia Controller.
  • This value can vary by up to 20% and is not normally repeatable due to component variance, change of direction, and application conditions.
  • This can be adjusted by changing the piezo drive voltage - refer to the controller manual for more details.
  • The axial force applied to the drive tip to achieve the specified step size. A minimum of 5 N is recommended to enhance stepping behavior.
  • A higher maximum load is possible but it may decrease the typical step size.
  • This actuator is not compatible with our Polaris mirror mounts.
  • Controllers are sold separately. These actuators can also be controlled using the legacy TIM101 T-Cube™ controller.

Required Controller
A KIM001 or KIM101 Controller is required to operate our PIAK10VF Piezo Inertia Actuator; the actuator cannot be operated using a standard piezo controller. These drivers have an internal sawtooth voltage signal generator capable of sending sub-millisecond pulses (steps) with controllable amplitudes from 85 V to 125 V.

For more information, please see the full web presentation.

Inertia Motor
Click to Enlarge

Three PIAK10VF Inertia Actuators Being Used in Place of the
1/4"-100 Adjustment Screws in our KS1TV Mirror Mount
(Mount Sold Separately)

Posted Comments:
No Comments Posted
Based on your currency / country selection, your order will ship from Newton, New Jersey
+1 Qty Docs Part Number - Universal Price Available
PIAK10VF Support Documentation
PIAK10VFCustomer Inspired! Vacuum-Compatible Piezo Inertia Actuator, 10 mm Travel, 1/4"-100 Mounting Thread
$872.73
Today
Back to Top

Re-Greasing Kit

Features

  • 1.5 cc Syringe of Apiezon 100 Grease
  • Convenient, Inexpensive Package that Reduces Waste
  • Prolongs Lifetime of Actuator
  • Ready to Dispense
  • Vacuum Compatible to 10-9 Torr

This Apiezon grease has excellent anti-seize properties. It contains PTFE for maximum lubricity and is ideal for re-lubricating the lead screw threads of our ZST, ZFS, and Z9 series actuators. It is supplied in a syringe for easy application and is recommended both for general use and for vacuum applications down to 10-9 Torr. It has an optimal working range of 10 to 30 °C (50 to 86 °F).

Note: It is recommended that the lead screw and end ball of the Z9, ZFS, and ZST actuators are lubricated every 10,000 cycles or whenever a squeaking noise is heard during motion.


Posted Comments:
No Comments Posted
Based on your currency / country selection, your order will ship from Newton, New Jersey
+1 Qty Docs Part Number - Universal Price Available
GKZ8 Support Documentation
GKZ8Grease Kit for Z9, ZFS, and ZST Actuators
$21.47
Today
Back to Top

Stepper and DC Servo Drive Cables

Thorlabs' DRV, ZST, and ZFS Stepper Motor Actuators, as well as our Z9 DC Servo Motor Actuators, come with cables for connecting to the required controllers. Thorlabs also offers separate cables that may be used as extension cables.

Stepper Motor Cables
Thorlabs offers a variety of cables to support several stepper motor actuator and controller combinations. Supported stepper motors include our ZST, ZFS, and DRV actuators; supported controllers include our BSC benchtop controllers, our KST201 K-Cube™ Controller, and our MST602 Rack Control Module. In order to see which cable is compatible with a given combination of stepper motor and controller, please see the table below. The pin assignment for each cable is given in the Pin Diagrams tab. Please note that these cables cannot be used with motors and controllers that do not match their pin assignment, even if the connectors are the same.

DC Motor Cables
The PAA632 is a 2.5 m cable for our Z9 series of DC motor actuators. This cable is intended to be used with the KDC101 K-Cube DC Servo Motor Controller. The pin assignment for this cable is given in the Pin Diagrams tab. Although it uses a 15-pin connector, this cable is not compatible with any of our stepper motors.



BSC Benchtop Controller and
 MST602 Rack Controller
KST201 K-Cube Controller KDC101 K-Cube Controllera
PAA612 (1 m) or
PAA613 (3 m)
PAA614 (1 m)b -
DRV Stepper Motor Actuators
- PAA614 (1 m) -
ZST and ZFS Stepper Motor Actuators
- - PAA632 (2.5 m)
Z9 DC Servo Motor Actuators
  • Green shading indicates hardware for DC servo motors.
  • The KST201 K-Cube Controller can be used to drive our DRV Stepper Motor Actuators (excluding the DRV208, which is incompatible) at a reduced velocity.

PAA612 and PAA613 Stepper Motor Cables

DA15 Male D-Type to DE15 Female D-Type

PAA612
DA15 Male Pin DE15 Female Pin Description
11 and 12 1 Limit Switch Ground
10 2 Reverse Limit Switch
9 3 Forward Limit Switch
7 4 Motor Phase B -
14 5 Motor Phase B +
8 6 Motor Phase A -
15 7 Motor Phase A +
6 9 Reserved for Future Use
5 13 5 V

PAA632 DC Servo Motor Cable

DE15 Male D-Type to DE15 Female D-Type

PAA632

DE15 Male Pin DE15 Female Pin Description
1 1 Ground
2 2 Forward Limit Switch
3 3 Reverse Limit Switch
5 5 Motor -
7 7 Motor +
10 10 5 V Encoder Supply
11 11 Encoder Channel A
13 13 Encoder Channel B

PAA614 Stepper Motor Cable

DE15 Male D-Type to DE15 Female D-Type

PAA632

DE15 Male Pin DE15 Female Pin Description
1 1 Ground
2 2 CCW Limit Switch
3 3 CW Limit Switch
4 4 Motor Phase B -
5 5 Motor Phase B +
6 6 Motor Phase A -
7 7 Motor Phase A +
10 10 +5 VDC
15 15 Ground

Posted Comments:
No Comments Posted
Based on your currency / country selection, your order will ship from Newton, New Jersey
+1 Qty Docs Part Number - Universal Price Available
PAA612 Support Documentation
PAA612APT Stepper Motor Cable, DA15 Male to DE15 Female, 1 m
$69.21
Today
PAA613 Support Documentation
PAA613APT Stepper Motor Cable, DA15 Male to DE15 Female, 3 m
$82.86
Today
PAA614 Support Documentation
PAA614Customer Inspired! APT Stepper Motor Cable, DE15 Male to DE15 Female, 1 m
$66.82
Today
PAA632 Support Documentation
PAA632APT DC Servo Motor Cable for Z9 Motors, DE15 Male to DE15 Female, 2.5 m
$65.93
Today
