| SM980-5.8-125 - Single Mode Optical Fiber, 970 - 1650 nm, Ø125 µm Cladding |
|
|
|
| Product Summary: |
Features
- Shipped from Stock
- No Minimums
- SM980-5.8-125 has a MFD Matched to Other Fibers used in EDFA Pump Laser Pigtails
This specialty single mode fiber is engineered for a variety of applications including biotechnology, laser delivery, and telecommunications. This fiber offers enhanced bend-insensitivity as well as reduced splice loss while providing excellent resistance to bend induced loss similar to that of conventional type fibers.
Specifications
- Operating Wavelength: 970 - 1650 nm
- Mode Field Diameter: 5.8 µm @ 980 nm, 6.2 µm @ 1064 nm, 10.4 µm @ 1550 nm
- Cladding Diameter: 125 ± 1 µm
- Coating Diameter: 245 µm ± 5%
- Cutoff Wavelength: 870 - 970 nm
- Short-Term Bend Radius: =5 mm
- Long-Term Bend Radius: =25 mm
- Maximum Attenuation: <3 dB/km
- Numerical Aperture: 0.13 - 0.15
|
|
|
|
|
|
|
