This specialty single mode fiber is engineered for a variety of applications including biotechnology, laser delivery, and telecommunications. These fibers offer enhanced bend-insensitivity as well as reduced splice loss while providing excellent resistance to bend induced loss similar to that of conventional fibers. The SM1250G80 offers a reduced outer diameter, which enhances resistance to mechanical failure through static fatigue, thus increasing the lifetime of the fiber.
Specifications
- Operating Wavelength: 1310 nm & 1550 nm
- Mode Field Diameter: 9.0 µm @ 1310 nm, 10.5 µm @ 1550 nm
- Cladding Diameter: 80 ± 1.0 µm
- Coating Diameter: 175 µm ± 5%
- Cutoff Wavelength: 1150 - 1250 nm
- Short-Term Bend Radius: =5 mm
- Long-Term Bend Radius: =12 mm (or 38 mm for 25 Year Life)
- Maximum Attenuation: =2 dB/km
- Numerical Aperture: 0.11 - 0.13
|
