| S630-HP - Single Mode Optical Fiber, 630 - 860 nm, Ø125 µm Cladding |
|
|
|
| Product Summary: |
This pure silica core, high-performance fiber is designed for applications that require low attenuation and higher resistance to radiation and color center formation compared to germanium doped fibers. This fiber is suitable for applications such as RBG components requiring couplers and diode pigtails.
Specifications
- Operating Wavelength: 630 - 860 nm
- Mode Field Diameter: 4.2 ± 0.5 µm @ 630 nm
- Cladding Diameter: 125 ± 1.0 µm
- Coating Diameter: 245 ± 15 µm
- Cutoff Wavelength: 590 ± 30 nm
- Short-Term Bend Radius: =6 mm
- Long-Term Bend Radius: =13 mm
- Maximum Attenuation: =10 dB/km @ 630 nm
- Numerical Aperture: 0.12
|
|
|
|
|
|
|
