| HB980T - Design Wavelength: 980 nm, Telecom Optimized PM Fiber, 6.0 µm MFD |
|
|
|
| Product Summary: |
Features
- Maintain Polarization State of Input
- Bow-Tie Style Fiber
- Design Wavelength: 980 nm
The HB980T Bow-Tie Style, Single Mode, Polarization Maintaining (PM) fiber is specially made to be used in telecom applications. Bow-tie style fiber uses trapezoidal prism stress rods. The HB1250T PM fiber has been optimized for telecom use with polarization multiplexing of EDFA pump lasers.
Specifications
- Design Wavelength: 980 nm
- Mode Field Diameter: 6.0 µm
- Numerical Aperture: 0.13 - 0.15
- Cut-off Wavelength: 870 - 970 nm
- Attenuation: <3 dB/km
- Beat Length: <2 mm
- Cladding: 125 ± 1 µm (HB800G: 80 ± 1 µm)
- Fiber Type: Bow-Tie Style
|
|
|
|
|
|
|
