Features
- Attach to SM or MM Fiber with FC/PC Connector
- Small Package Allows Easy Mounting
- Connects Directly to Oscilloscope with Built-in Bias-T
- Minimum Recommended Load Resistor: 50 Ohms
The DET02CFC/M InGaAs replaces the D400FC model, increasing the bandwidth to 1.2 GHz and still operating with a spectral range of 400 to 1100 nm. Some of the new features and improvements include higher bandwidth, easier battery access, and faster response. A M4 tapped mounting hole has been added, allowing easy mounting to our posts.
Specifications
- Material: Si
- Bandwidth: 1.2 GHz
- Wavelength Range: 400 – 1100 nm
- Fiber Input: FC/PC
- Max Peak Power: 18 mW
- Max Load Resistor: 50 Ohms
- Min Rise Time, t: 50 ps
- Fall Time: 250 ps
- Dark Current: 50 pA
- NEP (Max): 9.5 x 10-15 W/Hz1/2 (730 nm)
- Junction Capacitance: 1 pf (1.2 pF Max)
|
