Features
- Attach to SM or MM Fiber with FC/PC Connector
- Small Package Allows Easy Mounting
- Connects Directly to Oscilloscope with Built-in Bias-T
- Minimum Recommended Load Resistor: 50 Ohms
The DET01CFC/M InGaAs replaces the D400FC model, increasing the bandwidth to 1.2 GHz and still operating with a spectral range of 400 to 1100 nm. Some of the new features and improvements include higher bandwidth, easier battery access, and faster response. A M4 tapped mounting hole has been added, allowing easy mounting to our posts.
Specifications
- Material: InGaAs
- Bandwidth: 1.2 GHz
- Wavelength Range: 800 – 1700 nm
- Fiber Input: FC/PC
- Max Peak Power: 70 mW
- Max Load Resistor: 50 Ohms
- Min Rise Time, t: 100 ps
- Fall Time: 100 ps
- Dark Current: 0.7 nA
- NEP (Max): 1.5 x 10-15 W/Hz1/2 (1550 nm)
- Junction Capacitance: 0.94 pf (Typical)
|
