| AMA027/M - Adjustable Height, Pitch and Roll Platform |
|
|
|
| Product Summary: |
| The AMA027/M adjustable height, pitch, and roll platform is intended to allow an angled optical component to be positioned in front of one of our 3-Axis flexure stages. This add-on stage provides pitch and roll adjustment using the two labeled thumbscrews indicated in the photograph. Both the roll and pitch adjustment provide -8º and +4° of range, use of all three adjusters allows for the adjustment of the overall height of the platform. The amount of height adjustment ranges from -1mm to +4mm around the nominal height of 62.5mm for the entire assembly. |
|
|
|
