Features

  • Right-Angle or Equilateral Prisms for the IR
  • Choice of Two Substrates
    • Calcium Flouride Substrate for 180 nm - 8 µm
    • Zinc Selenium Substrate for 600 nm - 16 µm
    • Germanium Substrate for 2 - 16 µm
  • 10 mm or 25 mm Size Prisms

Materials

Calcium Flouride
CaF2 is commonly used for applications requiring high transmission in the infrared and ultraviolet spectral ranges. The material exhibits a low refractive index, varying from 1.35 to 1.51 within its usage range of 180 nm to 8.0 µm, as well as an extremely high laser damage threshold. Calcium fluoride is also fairly chemically inert and offers superior hardness compared to its barium fluoride, magnesium fluoride, and lithium fluoride cousins.

Zine Selenide
Zinc Selenide is ideal fo use in the 600 nm 16 µm range. It features low absorption (including in the red visible wavelength range) and high resistance to thermal shock. ZnSe is ideal for use in CO2 laser systems operating at 10.6 µm, including those with HeNe alignment lasers. Please note that, due to its low hardness, care should be taken when handling ZnSe optics.

Germanium
Due to its broad transmission range (2 - 16 µm) and opacity in the visible portion of the spectrum, Germanium is well suited for IR applications. Germanium has a refractive index of over 4 in the 2 - 16 µm range (see the Index of Refraction tab for details). It is also inert to air, water, alkalis, and acids (except nitric acid). Germanium's transmission properties are highly temperature sensitive. Germanium is nearly opaque at 100 °C and completely non-transmissive at 200 °C.

Note: Transmission data to the right is for two 25 mm right-angle prisms contacted into a cube. Click here to download substrate transmission data.

Please refer to the Prism Guide tab above for assistance in selecting the appropriate prism for your application. In addition to the IR-specific prisms shown here, Thorlabs offers a full line or prisms for use at wavelengths from 180 nm - 16 µm.

General Specifications
MaterialCaF2ZnSeGermanium
Wavelength Range180 nm - 8 µm600 nm - 16 µm2 µm - 16 µm
Surface Quality40-20 Scratch-Dig60-40 Scratch-Dig60-40 Scratch-Dig
Angular Tolerance±3 arcmin±10 arcmin±10 arcmin
Number of Polished FacesRight Angle: 3
Equilateral: 2
Surface Flatness @ 633 nmλ/2
Clear Aperture70%
Dimensional Tolerance+0.0/-0.3 mm
Right Angle Prism Drawing

Right-Angle Prisms

Item #MaterialA = B
(mm)
C
(mm)
H
(mm)
PS703CaF21014.110
PS7042535.425
PS701ZnSe1014.110
PS7022535.425
PS705Ge2535.425
1

Equilateral Prisms

Item #MaterialA=B=C=H
(mm)
PS862CaF210
PS86325
PS860ZnSe10
PS86125
PS864Ge10

CaF2 Index of Refraction
Click to Enlarge

Click Here to Download Index of Refraction Data

The index of refraction of various materials can be calculated via Sellmeier equations. Each material is empirically assigned a set of coefficients, through which the index of refraction can be calculated at any wavelength*.

Sellmeier Equation 1: Sellmeier Equation 1

Sellmeier Equation 4: Sellmeier Equation 4

Material**K1L1K2L2K3L3λmin* (µm)λmax* (µm)Plot
CaF25.676 x 10-12.526 x 10-34.711 x 10-11.008 x 10-23.8481.201 x 1030.239.7Click to View Index Plot
ZnSe4.2983.689 x 10-26.278 x 10-11.435 x 10-12.8962.208 x 1030.5518.0Click to View Index Plot
Material**ABCDEλmin* (µm)λmax* (µm)Plot
Ge9.2816.7304.418 x 10-12.131 x 10-13.870 x 1032.015.0Click to View Index Plot

*The Sellmeier equation is only accurate within the wavelength range specified by λmin and λmax.
**Sellmeier equation 1 should be used to calculate the index of ZnSe and CaF2, while Sellmeier equation 4 should be used to calculate the index of Ge.

Click Here to Download Index of Refraction Data

Angle of Minimum Dispersion

Angle of Minimum Deviation Through a Prism

If one were to use ray tracing techniques to determine the light propagation path due to the presence of the equilateral prism shown to the right, you would find that for most incidence angles, the angle of deviation of the transmitted ray (denoted by γ in the figure to the right) is roughly the same, regardless of the angle of incidence alpha considered. However, although the angle of deviation is largely unchanged, there is a minimum value that is obtainable. This angle is known as the minimum angle of deviation; it occurs when the light ray passing through the prism is parallel to the prism's base (as shown to the right), and therefore, alpha = β (i.e., the angle of the light ray entering the prism is identical to that of the light ray exiting the prism).

To illustrate the relationship between the incident, exit, and deviation angles in the triangle to the right, consider the equilateral triangle shown below, which is identical to the one shown to the right but has several more angles labeled. Using the geometric relationships that exist for vertical angles, it becomes apparant that A = alpha - θ1 and C = β - θ2. Since the angles A, B, and C define a triangle, we know that A + B + C = 180o, and thus, B = 180o - (A + C) = 180o - [(alpha - θ1) + (β - θ2)]. Finally, B + γ = 180o, so γ = 180o - B = [(alpha - θ1) + (β - θ2)].

Now, consider the triangle outlined in green in the figure below. Here, (90 - θ1) + (90 - θ2) + 60o = 180o. Thus, θ1 + θ2 = 60o. Substituting this relationship into the end result derived in the previous paragraph, yields γ = alpha + β - (θ1 + θ2) = alpha + β - 60o.

Minimum Angle of Deviation Figure 2

For the angle of minimum deviation, alpha = β, so there is a simple relationship between the angle of incidence and the angle of minimum deviation:

γ = alpha + β - 60o = 2alpha - 60o

By applying Snell's Law to the interfaces of prism and using a little calculus, a general equation for the relationship between the index of refraction of the equilateral prism n and the angle of minimum deviation γ can be obtained:

Minimum Dispersion Equation

At the design wavelength (633 nm), the indices of refraction for N-SF11 and F2 are 1.779 and 1.617, respectively. Solving for γ in the equation above yields 65.6o for N-SF11 and 47.9o for F2.

Selection Guide for Prisms

Thorlabs offers a wide variety of prisms, which can be used to reflect, invert, rotate, disperse, steer, and collimate light. Prisms are available in N-BK7, UV Fused Silica, F2, N-SF11, α-BBO, N-KZFS8, Ge, and CaF2. For prisms and substrates not listed below, please contact tech support.

Beam Steering Prisms

PrismMaterialDeviationInvertReverse or RotateIllustrationApplications
Right Angle PrismsN-BK7, UV Fused Silica, Germanium, or Calcium Fluoride90°90°No1

90° reflector, independent of entrance beam angle.

Used in optical systems such as telescopes and periscopes.

180°180°No1

180° reflector, independent of entrance beam angle.

Acts as a non-reversing mirror and can be used in binocular configurations.

Retroreflectors
and
Mounted Retroreflectors
N-BK7180°180°NoRetroreflector

180° reflector, independent of entrance beam angle.

Beam alignment and beam delivery. Substitute for mirror in applications where orientation is difficult to control.

Penta Prisms
and
Mounted Penta Prisms
N-BK790°NoNo1

90° reflector, without inversion or reversal of the beam profile.

Can be used for alignment and optical tooling.

Roof PrismsN-BK790°90°180o Rotation1

90° reflector, inverted and rotated (deflected left to right and top to bottom).

Can be used for alignment and optical tooling.

Dove Prisms
and
Mounted Dove Prisms
N-BK7No180°2x Prism Rotation1

Dove prisms may invert, reverse, or rotate an image based on which face the light is incident on.

Prism in a beam rotator orientation.

180°180°No1

Prism acts as a non-reversing mirror.

Same properties as a retro-reflector or right angle (180° orientation) prism in an optical setup.

Wedge PrismsN-BK7Models Available from 2° to 10°NoNo1

Beam steering applications.

By rotating one wedged prism, light can be steered to trace the circle defined by 2 times the specified deviation angle.

NoNoWedge Prism Pair

Variable beam steering applications.

When both wedges are rotated, the beam can be moved anywhere within the circle defined by 4 times the specified deviation angle.

Coupling PrismsRutile (TiO2) or GGGVariable*NoNoCoupling Prism

High index of refraction substrate used to couple light into films.

Rutile used for nfilm > 1.8

GGG used for nfilm < 1.8

* Depends on angle of incidence and index of refraction


Dispersive Prisms

PrismMaterialDeviationInvertReverse or RotateIllustrationApplications
Equilateral PrismsF2, N-SF11, Germanium, or Calcium FlourideVariable*NoNo1

Dispersion prisms are a substitute for diffraction gratings.

Use to separate white light into visible spectrum.

Pellin Broca PrismsN-BK7, UV Fused Silica, or CaF290°90°No1

Ideal for wavelength separation of a beam of light, output at 90°.

Used to separate harmonics of a laser or compensate for group velocity dispersion.

Dispersion Compensating Prism PairsFused Silica, CaF2, SF10, or N-SF14Variable Vertical OffsetNoNoDispersion-Compensating Prism Pair

Compensate for pulse broadening effects in ultrafast laser systems.

Can be used as an optical filter, for wavelength tuning, or dispersion compensation.



* Depends on angle of incidence and index of refraction

Beam Manipulating Prisms

PrismMaterialDeviationInvertReverse or RotateIllustrationApplications
Anamorphic Prism PairsN-KZFS8 or N-SF11Variable Vertical OffsetNoNo1

Variable magnification along one axis.

Collimating elliptical beams (e.g., laser diodes)

Converts an elliptical beam into a circular beam by magnifying or contracting the input beam in one axis.

Polarization Altering Prisms

PrismMaterialDeviationInvertReverse or RotateIllustrationApplications
Glan-Taylor, Glan-Laser, and α-BBO Glan-Laser Polarizers

Glan-Taylor:
Calcite

Glan-Laser:
α-BBO or Calcite

p-pol. - 0°

s-pol. - 112°*

NoNoGlan-Taylor Polarizer

Double prism configuration and birefringent calcite produce extremely pure linearly polarized light.

Total Internal Reflection of s-pol. at the gap between the prism while p-pol. is transmitted.

Rutile PolarizersRutile (TiO2)

s-pol. - 0°

p-pol. absorbed by housing

NoNoRutile Polarizer Diagram

Double prism configuration and birefringent rutile (TiO2) produce extremely pure linearly polarized light.

Total Internal Reflection of p-pol. at the gap between the prisms while s-pol. is transmitted.



Double Glan-Taylor PolarizersCalcite

p-pol. - 0°

s-pol. absorbed by housing

NoNoGlan-Taylor Polarizer

Triple prism configuration and birefringent calcite produce maximum polarized field over a large half angle.

Total Internal Reflection of s-pol. at the gap between the prism while p-pol. is transmitted.

Glan Thompson PolarizersCalcite

p-pol. - 0°

s-pol. absorbed by housing

NoNoGlan-Thompson Polarizer

Double prism configuration and birefringent calcite produce a polarizer with the widest field of view while maintaining a high extinction ratio.

Total Internal Reflection of s-pol. at the gap between the prism while p-pol. is transmitted.

Wollaston Prisms
Wollaston Polarizers
CalciteSymmetric
p-pol. and
s-pol. deviation angle
NoNoWollaston Prism

Double prism configuration and birefringent calcite produce the widest deviation angle of beam displacing polarizers.

s-pol. and p-pol. deviate symmetrically from the prism. Wollaston prisms are used in spectrometers and polarization analyzers.

Beam Displacing PrismsCalcite2.7 or 4.0 mm Beam DisplacementNoNoBeam Displacing Prism

Single prism configuration and birefringent calcite separate an input beam into two orthogonally polarized output beams.

s-pol. and p-pol. are displaced by 2.7 or 4.0 mm. Beam displacing prisms can be used as polarizing beamsplitters where 90o separation is not possible.

Fresnel Rhomb RetardersN-BK7

Linear to circularly polarization

Vertical Offset

NoNoFresnel Rhomb Quarter Wave

λ/4 Fresnel Rhomb Retarder turns a linear input into circularly polarized output.

Uniform λ/4 retardance over a wider wavelength range compared to birefringent wave plates.

Rotates linearly polarized light 90°NoNoFresnel Rhomb Half Wave

λ/2 Fresnel Rhomb Retarder rotates linearly polarized light 90°.

Uniform λ/2 retardance over a wider wavelength range compared to birefringent wave plates.

* s-polarized light is not pure and contains some p-polarized reflections.

Beamsplitter Prisms

PrismMaterialDeviationInvertReverse or RotateIllustrationApplications
Beamsplitter Cube
and
Mounted Beamsplitter Cube
N-BK7 - Grade A
400-700 nm
700-1100 nm
1100-1600 nm

50:50 splitting ratio, 0° and 90°

s- and p- pol. within 10% of each other

NoNoNon-polarizing Beamsplitter

Double prism configuration and dielectric coating provide 50:50 beamsplitting nearly independent of polarization.

Non-polarizing beamsplitter over the specified wavelength range.

Polarizing Beamsplitter Cube
and
Mounted Polarizing Beamsplitter Cube
SF2
420-680 nm
620-1000 nm
900-1300 nm
1200-1600 nm

p-pol. - 0°

s-pol. - 90°

NoNoPolarizing Beamsplitter Cube

Double prism configuration and dielectric coating transmit p-pol. light and reflect s-pol. light.

For highest polarization use the transmitted beam.

Loading Tag Cloud Loading...

Please Give Us Your Feedback

Email   Feedback On
(Optional)
Contact Me:
Your email address will NOT be displayed.


Please type the following key into the field to submit this form:
Click Here if you can not read the security code.
This code is to prevent automated spamming of our site
Thank you for your understanding.


Would this product be useful to you?       Little Use   1 2 3 4Very Useful

Enter Comments Below:

Characters remaining 8000
Posted Comments:
No Comments Posted
No tags entered
IR Right Angle Prisms
Right Angle Prism at 90°
Right Angle Prism at 180°

Available in 10 mm and 25 mm sizes, Thorlabs' high precision CaF2, ZnsSe, and Ge IR Right Angle Prisms can be used to deviate a light path by 90° or 180°, depending on which surface is used as the input for the light source (see schematics below). Due to total internal reflection (TIR), the image to the upper right demonstrates how the right angle prism can be used as a 90o reflector. When the input light is incident on one of the prism's legs, it undergoes TIR at the glass/air boundary of the hypotenuse and exits via the other prism leg. This 90o deviation of the input light makes the right angle prism a suitable alternative for a mirror.

The second image above shows how the right angle prism can be used as a 180° retroreflector. When the input light is incident on the face of the hypotenuse, it undergoes total internal reflection (TIR) at the glass/air boundary at the prism legs. It undergoes TIR a second time at the next prism leg and exits the hypotenuse in a path parallel to that of the input beam. Like the retroreflector, the 180o deviation of the light path is independent of the angle at which the light enters the prism.

Based on your currency / country selection, your order will ship from Newton, New Jersey
+1 Qty Docs Part Number - Universal/Imperial Price Available / Ships
PS703 Support Documentation PS703 CaF2 Right-Angle Prism, Uncoated, 10 mm $301.50
Today
PS704 Support Documentation PS704 CaF2 Right-Angle Prism, Uncoated, 25 mm $472.50
Today
PS701 Support Documentation PS701 ZnSe Right-Angle Prism, Uncoated, 10 mm $517.50
Today
PS702 Support Documentation PS702 ZnSe Right-Angle Prism, Uncoated, 25 mm $875.00
Today
PS705 Support Documentation PS705 Ge Right Angle Prism, Uncoated, 25 mm $765.00
Today
Add To Cart
IR Equilateral Dispersive Prisms
Right Angle Prism at 90°

Our IR Dispersive Equilateral Prisms, which are fabricated from either CaF2, ZnSe, or Ge, are available in 10 mm or 25 mm sizes. These prisms create less stray light than diffraction gratings, thereby eliminating the higher order problems typically associated with gratings.

Dispersive prisms are typically used at the minimum angle of deviation. This is the angle for which the wavelength of interest will travel parallel to the base of the prism, and the angle of incidence is equal to the angle of refraction when measured with respect to the normal of the prism face at the respective interface (see the Equilateral Tutorial tab for more information). At the minimum angle of deviation, a maximum clear aperture is achieved and reflective loss of P-polarized light is reduced since the angle of incidence is nearly Brewster's angle. For S-polarization, a custom anti-reflective coating can be used to minimize surface reflections.

Based on your currency / country selection, your order will ship from Newton, New Jersey
+1 Qty Docs Part Number - Universal/Imperial Price Available / Ships
PS862 Support Documentation PS862 CaF2 Equilateral Dispersive Prism, Uncoated, 10 mm $312.00
Today
PS863 Support Documentation PS863 CaF2 Equilateral Dispersive Prism, Uncoated, 25 mm $485.00
Today
PS860 Support Documentation PS860 ZnSe Equilateral Dispersive Prism, Uncoated, 10 mm $522.00
Today
PS861 Support Documentation PS861 ZnSe Equilateral Dispersive Prism, Uncoated, 25 mm $900.00
Today
PS864 Support Documentation PS864 Ge Equilateral Dispersive Prism, Uncoated, 25 mm $780.00
Today
Add To Cart
