Multimode Hybrid Fiber Optic Patch Cables


Related Items













Multimode Hybrid Fiber Optic Patch Cables

Item #CoreNAWavelength RangeFiber Used
M23LØ10 µm0.10280 - 750 nmHPSC10
M39LØ25 µm0.10280 - 750 nmHPSC25
M16LØ50 µm0.22400 to 2400 nm (Low OH)AFS50/125Y
M18LØ105 µm0.22400 to 2400 nm (Low OH)AFS105/125Y
M75LØ200 µm0.39400 to 2200 nm (Low OH)FT200EMT
M12LØ300 µm0.39400 to 2200 nm (Low OH)FT300EMT
M76LØ400 µm0.39400 to 2200 nm (Low OH)FT400EMT

Features

  • FC/PC (2.0 mm Narrow Key) to SMA 905 Multimode Adapter Cables
  • Many Fiber Types/Core Sizes Available (See Table to the Right)
  • 1 m and 2 m Cables with Ø3 mm Orange Furcation Tubing
  • Custom Cables Available (See the Custom Cables Tab)

These multimode fiber optic patch cables consist of step-index multimode fiber and have an FC/PC connector on one end and an SMA 905 connector on the other end. They are available from stock in 1 m and 2 m lengths. If you do not see a stock cable suitable for your application, please use the Custom Cables tab above to request a cable that meets the needs of your specific application. We have extensive patch cable capabilities; a large, diverse stock of bare fiber; and very rapid turnaround times.

Each patch cable includes two protective caps that shield the cable ends from dust and other hazards. Additional CAPF Fiber Caps for the FC/PC-terminated end and CAPN Fiber Caps for the SMA-terminated end are also sold separately.

Custom Patch Cables
In-Stock Multimode Fiber Optic Patch Cable Selection
Step-IndexGraded Index
SMAFC/PCFC/PC
to SMA		High-Power
SMA		Solarization-
Resistant, SMA		AR-Coated
SMA		Bundles
SMA		Optogenetics
FC/PC		Optogenetics
SMA		FC/PC
Loading Tag Cloud Loading...

Please Give Us Your Feedback

Email   Feedback On
(Optional)
Contact Me:
Your email address will NOT be displayed.


Please type the following key into the field to submit this form:
Click Here if you can not read the security code.
This code is to prevent automated spamming of our site
Thank you for your understanding.

Would this product be useful to you?       Little Use   1 2 3 4Very Useful

Enter Comments Below:

Characters remaining 8000
Posted Comments:
No Comments Posted
Click on any phrase below to search our site using our new Search Engine:
1 m   1 m cable   10 µm core fiber   105 µm core fiber   1m   2 m   2 m cable   200 µm core fiber   25 µm core fiber   2m   300   300 µm   300um   400 µm core fiber   50 µm core fiber   adapter   adapter cable   adapter cord   cable   cord   core   FC/PC   FC/PC to SMA   fiber   hybrid   hybrid cable   MM   MM patch cable   mode fiber   multi   multi mode fiber   Multimode   Multimode fiber   optogenetics   patch   SM patch cord   SMA   um
Ø10 µm, 0.10 NA, FC/PC to SMA Patch Cable
FiberMax PowerCore
Diameter		Cladding
Diameter		Coating
Diameter		NAWavelength
Range		Attenuation
Plot		Ferrule
Material		Jacket
HPSC10 500 mW* 10 ± 3 µm 125 ± 2 µm 245 ± 10 µm 0.100 ± 0.015 280 - 750 nm icon FC/PC: Ceramic
SMA: Stainless		 FT030
(Ø3 mm)

*The maximum power of the patch cable is lower than the maximum power of the bare fiber.

Based on your currency / country selection, your order will ship from Newton, New Jersey
+1 Qty Docs Part Number - Universal/Imperial Price Available / Ships
M23L01 Support Documentation M23L01 Ø10 µm, 0.10 NA, FC/PC to SMA Fiber Patch Cable, 1 m $94.27
Today
Add To Cart
Ø25 µm, 0.10 NA, FC/PC to SMA Patch Cable
FiberMax PowerCore
Diameter		Cladding
Diameter		Coating
Diameter		NAWavelength
Range		Attenuation
Plot		Ferrule
Material		Jacket
HPSC25 500 mW* 25 ± 3 µm 125 ± 2 µm 245 ± 10 µm 0.100 ± 0.015 280 - 750 nm icon FC/PC: Ceramic
SMA: Stainless		 FT030
(Ø3 mm)

*The maximum power of the patch cable is lower than the maximum power of the bare fiber.

Based on your currency / country selection, your order will ship from Newton, New Jersey
+1 Qty Docs Part Number - Universal/Imperial Price Available / Ships
M39L01 Support Documentation M39L01 Ø25 µm, 0.10 NA, FC/PC to SMA Fiber Patch Cable, 1 m $96.25
Today
Add To Cart
Ø50 µm, 0.22 NA, FC/PC to SMA Patch Cable
FiberCore
Diameter		Cladding
Diameter		NABend Radius
(Short Term/Long Term)		Wavelength
Range		Attenuation
Plot		Ferrule
Material		Jacket
AFS50/125Y 50 ± 1 µm 125 +1/-3 µm 0.22 ± 0.02 12 mm / 24 mm 400 to 2400 nm
(Low OH)		 icon FC/PC: Ceramic
SMA: Stainless		 FT030
(Ø3 mm)
Based on your currency / country selection, your order will ship from Newton, New Jersey
+1 Qty Docs Part Number - Universal/Imperial Price Available / Ships
M16L01 Support Documentation M16L01 Customer Inspired! Ø50 µm, 0.22 NA, FC/PC to SMA Fiber Patch Cable, 1 m $72.49
Today
Add To Cart
Ø105 µm, 0.22 NA, FC/PC to SMA Patch Cable
FiberCore
Diameter		Cladding
Diameter		NABend Radius
(Short Term/Long Term)		Wavelength
Range		Attenuation
Plot		Ferrule
Material		Jacket
AFS105/125Y 105 µm ± 2 % 125 µm +1/-3 µm 0.22 ± 0.02 12 mm / 24 mm 400 to 2400 nm
(Low OH)		 icon FC/PC: Ceramic
SMA: Stainless		 FT030
(Ø3 mm)
Based on your currency / country selection, your order will ship from Newton, New Jersey
+1 Qty Docs Part Number - Universal/Imperial Price Available / Ships
M18L01 Support Documentation M18L01 Customer Inspired! Ø105 µm, 0.22 NA, FC/PC to SMA Fiber Patch Cable, 1 m $71.95
3-5 Days
Add To Cart
Ø200 µm, 0.39 NA, FC/PC to SMA Patch Cables
FiberCore
Diameter		Cladding
Diameter		NABend Radius
(Short Term/Long Term)		Wavelength
Range		Attenuation
Plot		Ferrule
Material		Jacket
FT200EMT 200 ± 5 µm 225 ± 5 µm 0.39 ± 0.02 9 mm / 18 mm 400 to 2200 nm
(Low OH)		 icon FC/PC: Ceramic
SMA: Stainless		 FT030
(Ø3 mm)
Based on your currency / country selection, your order will ship from Newton, New Jersey
+1 Qty Docs Part Number - Universal/Imperial Price Available / Ships
M75L01 Support Documentation M75L01 Ø200 µm, 0.39 NA, FC/PC to SMA Fiber Patch Cable, 1 m $84.94
Today
M75L02 Support Documentation M75L02 Ø200 µm, 0.39 NA, FC/PC to SMA Fiber Patch Cable, 2 m $87.49
Today
Add To Cart
Ø300 µm, 0.39 NA, FC/PC to SMA Patch Cables
FiberCore
Diameter		Cladding
Diameter		NABend Radius
(Short Term/Long Term)		Wavelength
Range		Attenuation
Plot		Ferrule
Material		Jacket
FT300EMT 300 ± 6 µm 325 ± 10 µm 0.39 ± 0.02 11 mm / 22 mm 400 to 2200 nm
(Low OH)		 icon FC/PC: Ceramic
SMA: Stainless		 FT030
(Ø3 mm)
Based on your currency / country selection, your order will ship from Newton, New Jersey
+1 Qty Docs Part Number - Universal/Imperial Price Available / Ships
M12L01 Support Documentation M12L01 Ø300 µm, 0.39 NA, FC/PC to SMA Fiber Patch Cable, 1 m $85.90
Today
M12L02 Support Documentation M12L02 Ø300 µm, 0.39 NA, FC/PC to SMA Fiber Patch Cable, 2 m $89.10
Today
Add To Cart
Ø400 µm, 0.39 NA, FC/PC to SMA Patch Cables
FiberCore
Diameter		Cladding
Diameter		NABend Radius
(Short Term/Long Term)		Wavelength
Range		Attenuation
Plot		Ferrule
Material		Jacket
FT400EMT 400 ± 8 µm 425 ± 10 µm 0.39 ± 0.02 20 mm / 40 mm 400 to 2200 nm
(Low OH)		 icon FC/PC: Ceramic
SMA: Stainless		 FT030
(Ø3 mm)
Based on your currency / country selection, your order will ship from Newton, New Jersey
+1 Qty Docs Part Number - Universal/Imperial Price Available / Ships
M76L01 Support Documentation M76L01 Ø400 µm, 0.39 NA, FC/PC to SMA Fiber Patch Cable, 1 m $86.56
3-5 Days
M76L02 Support Documentation M76L02 Ø400 µm, 0.39 NA, FC/PC to SMA Fiber Patch Cable, 2 m $90.28
3-5 Days
Add To Cart
