Horizontal Mounting Plate for 66 mm Optical Rails
Horizontal Mounting Plate for 66 mm Optical Rails
Zoom
XT66P3 App shot
Click to Enlarge
  • Attach a 66 mm Rail Horizontally Along a Breadboard or Optical Table
  • Four Counterbored Mounting Slots for 1/4"-20 or M6 Cap Screws

The XT66P3 Horizontal Mounting Plate allows 66 mm optical rail constructions to be mounted on top of a breadboard or another 1/4"-20 (M6) compatible assembly. The top-located clamp tightens around the rail once it has been slid into its desired position and is secured by two spring-loaded M4 cap screws.

The counterbored slots at the corners of the mounting plate make it easier to align the rail with the tapped hole array on an imperial or metric breadboard.

Based on your currency / country selection, your order will ship from Newton, New Jersey
+1 Qty Docs Part Number - Universal/Imperial Price Available / Ships
XT66P3 Support Documentation XT66P3 Horizontal Mounting Plate for 66 mm Optical Rails $52.00
Today
Add To Cart
Vertical Mounting Plate for 66 mm and 34 mm Optical Rails
Vertical Mounting Plate for 66 mm and 34 mm Optical Rails
Zoom
XT66P1 App shot
Click to Enlarge
  • Mount 66 mm or 34 mm Rails Vertically on an Optical Table or Breadboard
  • Four Counterbored Mounting Slots for 1/4"-20 or M6 Cap Screws
  • Includes Four M3 Cap Screws

The XT66P1 Vertical Mounting Plate orients a standard 66 mm or 34 mm rail in the direction orthogonal to the breadboard plane, enabling three-dimensional rail constructions. It bolts to the rail end using the four included M3 cap screws.

The counterbored slots are mechanically compatible with both imperial and metric breadboards.

Based on your currency / country selection, your order will ship from Newton, New Jersey
+1 Qty Docs Part Number - Universal/Imperial Price Available / Ships
XT66P1 Support Documentation XT66P1 Vertical Mounting Plate for 34 mm & 66 mm Optical Rails $34.00
Today
Add To Cart
Additional 66 mm Construction Accessories
  • 66 mm Clamps and Angle Brackets

  • 66 mm Breadboard Mounting

  • 66 mm Rail Joiners

  • Rail Size Adapters
